Specifications
| Product Number | CH-05070-Y |
| Chain Style | Straight Link |
| Unit for pricing | 1 Ft. |
| Application | Lifting |
| Grade | 70 |
| Material | Steel |
| Finish | Zinc Yellow-Chromate Plated |
| Trade Size | 1/2 |
| Metric Trade Size | 13 |
| Thickness | 0.52" |
Inside |
|
| Width | 0.81" |
| Length | 1.56" |
| Capacity | 3150 |
| Weight per ft. | 2.7 lbs. |
| Approximate Number of Links per Foot | 7 |
| For Fitting Thickness | 3/4" |
| Maximum Temperature | 400º |
| For Use Outdoors | No |
| Specifications Met | ASTM A413, NACM (National Association of Chain Manufacturers) |
| RoHS | RoHS 3 (2015/863/EU) Compliant |
| REACH | Not Compliant |
