Metric Button Head Cap Screw Full Thread M8 * 1.25 * 30mm [Torx Pin-In]

Metric Button Head Cap Screw Full Thread M8 * 1.25 * 30mm [Torx Pin-In]

5.96 $ CAD
5.96 $ CAD
Sale Sold out
Shipping calculated at checkout.
Title
Download

This pan head screw is 30 mm long and has an M8 * 1.25 mm thread (fully threaded). Made of A2 stainless steel (equivalent to 304 SS), it offers excellent corrosion resistance in dry and humid environments.

The cup point and A2 stainless steel (equivalent to 304 stainless steel) increase its compressive strength and provide a tensile strength and hardness of 70,000 psi (Rockwell B70). In addition, it has a shear strength of 42,000 psi.

ISO Metric Thread | Coarse threads are an industry standard. These screws are classified to DIN 7380 and conform to dimensional standards.

View full details

Specifications
Product Number VPSBM-08030-TA
Nominal Diameter M8 * 1.25mm
Length 30mm
Material and/or Plating A2 Stainless Steel [Equivalent 304 SS]
System of Measurement Metric

Thread Specifications
Threading Fully Threaded
Type ISO Metric Pitch | Coarse
Direction Right Hand
Size M8 * 1.25mm
Fit Class 5g6g

Head Specifications
Type Button
Profile Standard
Diameter 17.80mm
Height 4.40mm
Drive Style Torx Pin-In
Drive Size 5.00mm

Strength Specifications
Tensile Strength | Hardness 70,000 psi | Rockwell B70
Shear Strength 42,000 psi
Classification DIN 7380
