Specifications
Specifications |
|
---|---|
Nominal Diameter | M5 |
Length | 12 mm |
Thread Pitch | 0.8 mm |
Material | Acier inoxydable AISI 304 |
Finition | Black Oxide |
Système de mesure | Métrique |
Thread Specifications |
|
Threading | Fully Threaded |
Type | Metric | Coarse |
Direction | Right Hand |
Size | M5 × 0.8 |
Shank Length | 12 mm |
Fit | Class 6g |
Head Specifications |
|
Type | Flat Large Mince |
Profile | Standard |
Diameter | 9 mm |
Height | 1.5 mm |
Drive Style | Hex Socket / Standard |
Neck Specifications |
|
Form | Cylindrique |
Strength Specifications |
|
Grade/Class | A2-70 |
Tensile Strength | 700 MPa |
Shear Strength | 450 MPa |
Classification | ISO 3506 |
